High Speed Ethernet Recorders
Rack Mount Ethernet Recorders
- Full rate ethernet capture, record and playback
- 10- 200 Gbe-Zero Packet Loss
- 30-360 TB Storage
- Inline FPGA Data Processing
Ruggedized Ethernet Recorders
- Full rate ethernet capture, record and playback
- 10- 100 Gbe-Zero Packet Loss
- 30-360 TB Storage
- Inline FPGA Data Processing
- MIL-STD-810
- Rack, tray or bulkhead mounted version
SWAP Optimized Ethernet Recorders
- Full rate ethernet capture, record and playback
- 10-40 Gbe-Zero Packet Loss
- Up to 60 TB Storage
RF Modules and Cards
3UVPX and Modular Transceivers
- Coherent 4-64 Channel Receivers/Transceivers
- RF Operation: 0.02 – 20 GHz
- 2 GHz Instantaneous Bandwidth
- 2-4 GHz IF output
- Programmable 32dB digital attenuators, RF tunable bandpass filters and fast tuning Local Oscillators
- Integrated LOs
- Integrated Ref CLK or external Ref CLK
- SOSA Aligned Card Available
Convertors
- 500 MHz – 18 GHz Dual Channel Convertor
- Digital Programmable Attenuation CCA DC-18 GHz, 30dB
- Digital Programmable Filter CCA, DC-18 GHz
- Ku RF Programmable Upconverter CCA
- Ku RF Programmable Downconverter CCA
- 2-4 GHz IF Filter CCA, Custom IF CCA
- USB-C Power / Control CCA
- Optional 50 GHz Extender
0.74” x 1.02” x 1.38”, 1 oz, 13w
Low-Cost Multi-Channel Transceiver
- 4 RX and 4 TX channels with optional phase coherency
- 1 MHz to 6 GHz tuning range
- Up to 200 MHz channel bandwidth
- Standard network interfaces for easy workstation connectivity
- VDB: 1GbE via RJ45
- ML2B: 40GbE via 4xSFP+
- Maintained in line with the MORA specification
- Works with MSRP Generator and MORA Explorer
Unmanned Systems
Ultra Portable T-UAS
- Payload: 1-2 lbs (.45-.9 kg)
- Tether length: 200 ft (61 m)
- Drone weight: 7 lbs (3.2 kg) without payload
- Max diameter: 46 in (117 cm)
- Power required: 800W 110VAC – 1200W 110 VAC depending on payload weight
Medium Lift T-UAS
- Payload: 2-14 lbs (.9-6.4 kg)
- Tether length: 300 ft (90 m)
- Drone weight: 16 lbs (7.3 kg) without payload
- Max diameter: 70 in (178 cm)
- Power required: 1500W 110VAC – 3500W 220VAC depending on payload weight
Medium Lift Mobile Ops T-UAS
- Payload: 2-10 lbs (.8-4.5 kg)
- Tether length: 300 ft (90 m)
- Drone weight: 21 lbs (9.5 kg) without payload
- Max diameter: 70 in (178 cm)
- Power required: 1500W 110 VAC – 3500W 220VAC (depending on payload weight)
DF Sensors
Portable HF Direction Finding
- 3D Fully Polarimetric
- 26 Lbs
- 2-50 MHz, 2MHz-1GHz
- 8 CH Phase Coherent SDR
Low SWAP Wideband DF
- 2MHz – 6 GHz or 2 MHz – 18 GHz
- 360 deg precision DF
- Mast, Vehicle, TUAS or Aircraft applications
- 11 lbs
Very LOW SWAP Wideband DF
- 360 deg of precision DF
- 30- 6000 MHz
- 3.5 lbs
- 6 in. dia x 7 in. length
Wireless Network Solutions
Network Characterization and Survey
- GSM/GPRS/EDGE
- CDMA2000/1xRTT/EvDO
- UMTS/HSPA
- WIMAX
- LTE-FDD
- LTE-TDD and PTT
- D-PTT
- Wi-Fi
- 5G FR1
Data Analytics
Performs automated analysis across all collected data
- Pattern of Life (POL)
- Link Analysis
- Historical CDR Searches
- Human Language Detection and ID
Open Standards Development Platforms
MORA Ecosystem for Rapid Development
MORA Development Box
Low-cost MORA aligned multi-channel RF transceiver device offering a simple development solution for those exploring MORA
- 4 RX and 4 TX channels with optional phase coherency
- 1 MHz to 6 GHz tuning range
- Up to 200 MHz channel bandwidth
- Standard network interfaces for easy workstation connectivity
- VDB: 1GbE via RJ45
- ML2B: 40GbE via 4xSFP+
- Maintained in line with the MORA specification
- Works with MSRP Generator and MORA Explorer
Interface Solutions
High Performance FPGA based Optical, Ethernet and 1394 (XMC, PMC, PCIe and PCI) cards
V1160 Dual-Port 100G Rugged Ethernet XMC Card
V1161 Programmable 100G Rugged Ethernet XMC ASoC Card
V1163 12-Port Rugged XMC ASoC Card
V1152 12-Port XMC FPGA Card
V1144 12-Port 1394b-AS5643 XMC FPGA Card
V5051 Quad-Port PCI Express FPGA Card
NI PXIe-6592 ARINC 818 Test Solution
NI PXIe-7902 Serial RapidIO® Test Solution
Processing
- SBC, DSP and GPU processing cards
- Intel Ice Lake & Raptor Lake P
- Versal FPGA
- 3UVPX and XMC
- SOSA aligned cards available.
- Ruggedized
Networking Cards
FR 361
- 10G, 40G, & 100G Ethernet Switch 3U VPX – SOSA Aligned
- L2/L3 Managed Ethernet Switch
- Two sets of independent Layer 2
- Ethernet enclaves
- Control processor to support physically separate
- Control and Data planes for highly secured 3U VPX systems
- Dual core ARM processor
- -40C to 85C Conduction Cooled
NIRAH
- 4-core Intel Tiger Lake H Managed Switch
- 16 Port Switch Layer 2/3
- 5x 10/100/1000-Base-KX
- 6x 1/10G-Base-KX/KR
- 4 x 10GE Front Panel Optical
- (HSR) (PRP) (TSN)
- AUX_CLK (1PPS) support
- -40°C to 85°C
- Line Rate Switching Engine
Systems
Website information coming soon
- EW/SIGINT Solutions
- Air, ground mobile, surface, and fixed site systems
